With Hager it’s not just the hardware. Hager HS4 is an ideal system which enables the upgrade of existing mechanical locks to electronic access control. Besides a comprehensive line of electronic cylinders and software, Hager offers the business, marketing and training components to launch the locksmith as a Hager dealer.
Founded in 1849 by Charles Hager, Hager Companies is globally recognized as a leader in door hardware. Still family owned today, the Hager family continues to expand on a rich 167-year legacy of quality, reputation, and excellence and it is our goal to provide a complete line of quality door hardware to our customers at a competitive price with impeccable customer service.
Based in Spain, Salto Systems, Inc. was founded in 2001 by access control professionals looking for a better, more economical solution. Salto translates to Jump in English. During the past 16 years, over 19,500 customers in over 90 countries have made the jump to a dynamic, reliable, and cost-effective access control locking solution.
Through a new partnership, Hager powered by Salto can design a customizable electronic access control solution by using different platform types for various door openings to best fit a facility’s overall access control and security needs. These include standalone, virtually networked, wired and wireless components, all working within a single intuitive software system.
HS4 combines the largest portfolio of access control products under a single software system. From readers to cylindrical locks, mortise locks, deadbolts, padlocks, locker locks and cam locks, every opening in a building can be secured seamlessly, using a wide variety of credentials.
HS4 provides the ability to manage up to 65,000 openings and 4 million users in a single software package. From a small commercial office environment to a large institutional facility HS4 enables both virtual and real-time monitoring to meet the diverse needs of today’s access control managers. Audit trails can be collected seamlessly whichever platform is being utilized.
Become a Dealer
Becoming a Hager powered by Salto systems authorized partner starts with training. Hager Companies offers three levels of authorization training. Upon successful completion, you will be certified to market, promote, install, and support the Hager powered by Salto system.
Hager powered by Salto partners are expected to meet specific criteria and to make any needed investments to be successful in their markets.
In return, Hager partners will have the opportunity to establish and maintain professional relationships within their markets.
For information on training, contact your local representative or email [email protected].
Marketing Support: As a Hager powered by Salto partner, you will have access to a library of Marketing materials to help you promote HS4 in your markets.
Sales Support: From time to time, you may want to provide your sales team with additional sales training or rely on Hager for additional sales and design support. As a Hager powered by Salto partner, you will have access to a network of extensively training and experienced sales representatives, trainers, and sales engineers.
Technical Support: Hager Technical Service department has access to Engineering resources, Research & Development resources, Operational resources, and Product Management resources.
Training: To receive and maintain your certification as a Hager powered by Salto partner, you must attend the required training seminars, including any training updates that may occur from time to time as product modifications, updates or improvements are made. To commission projects and service end-user needs at all times, you must ensure that at least one trained and one accredited staff member is available in each state or territory where you offer Hager powered by Salto solutions.
Hager HS4 Product Line
- HS4 Escutcheon - Mortise
- HS4 Escutcheon - Cylindrical
- HS4 Escutcheon - Exit Trim
- HS4 Mini Series - Escutcheon Cylindrical
- HS4 AElement
- HS4 GEO Cylinder
- HS4 Locker Lock
- Management Tools
- HS4 Wall Readers & Control Units
- HS4 Credentials
- HS4 Software
- HS4 - KS
- Wireless Gateways & Nodes
HS4 GEO Cylinder
The HS4 GEO cylinder has an extensive range of compact sizes that are designed to allow electronic access on door openings where a full size electronic lockset is not possible or required. They are available wire-free and in half, double, rim, mortise, cam, cylinder with thumb turn and padlock cylinders.
Certifications:
- BHMA Certified ANSI A156.5 Grade 2
- ANSI A250.13 Severe Windstorm Resistant Component
- UL/cUL Listed for all functions up to 20 minutes for "A" label single doors
- UL10C Positive Pressure Rated
- UL10B Neutral Pressure Rated
- ADA - Thumbturn
- Lifetime warranty
Exposed Trim:- Wrought brass, stainless steel or bronze
Mechanism:- Steel, zinc dichromate plating
Keys: - Two operating keys supplied per lock
Cylinders:
- Brass 6-pin - Keyed Different - Schlage C Keyway - standard
- Cylinder drilled 6 pin, Keyed 5 pin - standard
- Other keying options, including keyed 6 pin, available from factory
- Zero bit cylinders will be 6 pin keyed - standard
- SFIC uncombinated or combinated, brass 6 pin or 7 pin cores sold separately
DOOR THICKNESS:
- 1-3/8'' - 1-3/4'' (35 mm - 45 mm) - Standard
- 1-3/4" (35 mm) Only - 3214 SFIC and 3216
- 2" - 2-1/4" (51 mm - 57 mm) available for conventional cylinder - Must specify
BACKSET: - 2-3/4'' (70 mm) – Standard - 2-3/8'' (60 mm) - Optional
LATCHBOLT: - 1'' (25 mm) Throw - Brass with concealed hardened steel roller to prevent sawing or cutting
- 2-1/4'' x 1-1/8'' (57 mm x 29 mm) square corner faceplate
STRIKES:
- 3930 Square Corner, 1-1/8'' x 2-3/4'' (29 mm x 70 mm) with dustbox - Standard
- 3929 ASA Deadbolt Strike - Optional
STANDARD DOOR PREP:
- Cylinder hole: 2-1/8'' (54 mm) diameter (cross bore)
- Latch hole: 1'' (25 mm) diameter (edge bore)
FINISHES: US3, US4, US10, US10B, US26D, US32, US32D
FUNCTIONS: 15 - Cylinder x Thumbturn,
CONVERSION KITS:
US3 - 2-639-0320
US4 - 2-639-0321
US26 - 2-639-0325
US26D - 2-639-0326
OPTIONS:
Split finish
Additional deadbolts and strikes available
HS4 GEO Deadbolt HG32 Double Cylinder
Applications: Designed for applications where a deadlock lock is already in place or desired. Auxiliary and primary locking, on-handed
LOCK TYPES:- Hager 3214 Series deadlock equivalent - double cylinder
PROGRAMMABLE LOCK MODES:
- Programs can be customized by user and by opening
- Standard - locked at all times
- Automatic Opening - 8 pairs of "hands-free" timed lock and unlocks per day with holidays
- Toggle - present card to lock, present card to unlock
- Timed Toggle - present card to lock, present card to unlock depending on· schedule
Visual Feedback - Green light ring indicates granted access; red light ring indicates denied access. Audio feedback is optional.
ID TECHNOLOGIES:
- Mifare (DESfire EV1, Plus, Ultralight C, Classic - ISO/IEC14443)
- HID iClass®
- NFC
MANAGEMENT SOFTWARE:
- Salto ProAccess SPACE
ADDITIONAL OPTIONS:
IP66 - dust and water resistant rating, recommended for outdoor use
ADA Grips - black, blue, green, red, white, yellow
Rigid Grips - black, green, red, white, yellow
POWER SOURCE: (1) lithium CR2 battery 40,000 - 60,000 transactions (batteries can be replaced without cylinder removal)
CYLINDER MECHANICAL SPECIFICATIONS
DIMENSIONS: - 1.6" from mechanical cylinder face, 1.5" in diameter
WARRANTY: Electronics & Trim - one year, Grade 2 Deadbolt - one year
CERTIFICATIONS:
- Declaration of Conformity CE
USE OF RADIO FREQUENCY SPECTRUM:
- ETSI EN 302 291-1 V1.1.1 (2005-07); ETSI EN 302 291-2 V1.1.1 (2005-07)
ELECTROMAGNETIC COMPATIBILITY:
- ETSI EN 301 489-1 (2011-09); ETSI EN 301 489-3 (2002-08)
SECURITY REQUIREMENTS:
- EN 60950-1 (2007)
DEADLOCK:
- BHMA Certified ANSI A156.3 Grade 1
- ADA - Thumbturn
ENVIRONMENT:
- EP55 (IP66 optional)
Additional HS4 Products
HS4 GEO Cam Lock HG11 Cylinder: Designed for cabinets and cupboards equipped with cam lock mechanisms
Programmable Lock Modes:
Programs can be customized by user and by opening
Standard - locked at all times
Automatic Opening - 8 pairs of "hands-free" timed lock and unlocks per day with holidays
Toggle - present card to lock, present card to unlock
Timed Toggle - present card to lock, present card to unlock depending on schedule
GEO DEADBOLT RETROFIT KIT HG03: This product is used with Hager 3710 Series Interconnected lock and Hager 3215 Series Deadlock
Programmable Lock Modes:
- Programs can be customized by user and by opening
- Standard - locked at all times
- Automatic Opening - 8 pairs of "hands-free" timed lock and unlocks per day with holidays
- Toggle - present card to lock, present card to unlock
- Timed Toggle - present card to lock, present card to unlock depending on schedule
HS4 GEO Mortise HG02 Cylinder: Designed for applications where fitting an escutcheon is not possible, for example antique doors, post boxes, server racks, cabinets, padlocks, suitable for emergency exits
